EVK-pITX-OSM-iMX93 Evaluation Board
- Flexible prototyping vehicle
- An "application ready" single board computer
- Dimensions (pico-ITX): 100mm x 72mm (W x L)
- Availability guaranteed until 2038
Feature Highlights
- Fixed DC 12 Power input with 2.5mm DC Jack
- RTC backup battery connector
- HDMI (1080p60, via MIPI-DSI interface)
- 2 x 10/100/1000Mbps RJ-45 connectors with magnets
- 2 x USB 2.0 host type A connectors, 1 x mini USB client connector
- 1 x reset button
- 1 x 2-LANE MIPI-CSI (0.5mm 24P FPC(V) Connector)
- 2 x 6P SPI Header
- 1 x M.2 Type 2230 Key E Connector (4-bit SDIO/USB 2.0/4-wire UARTs
- 1 x 2.0mm 50P Expansion Header (2 x CAN-FD/3 x UARTs/2 x USB 2.0 Host/1 x SPI/ 2 x I2Cs/6x GPIOs)
- 1 x microSD connector
- 2 x LEDs (Power and Programmable)
- Form Factor: pico-ITX (72mm x 100mm, L x W)
Document Deliverable
- OSM 1.1 Carrier Board Design Guide
- User's Manual
- Carrier Board Reference Schematics (pdf and OrCAD format)
- Carrier Board Schematics Checklist
- PinMux File
- OSM-iMX93-LF 3D File
- OSM-iMX93-LF EDA Model
Ordering Information
- P/N: EVK-pITX-OSM-iMX93
Packing List
- 1 x pITX-OSM-iMX93 pico-ITX SBC
- 2 x M3 screws (for heat sink)
- 1 x Heat Sink
- 1 x RTC Battery and Cable
- 1 x 12V/3.5A Power Supply
- 1 x 32GB image pre-installed microSD card
Optional Accessaries
50P I/O Expansion Board
- P/N: pITX-IOB-2201
Features:
1 x USB 3.0+2.0 dual-stack Type A connector
1 x USB 2.0 Type A Connector
1 x SPI Header
3 x RS232, 1 x RS485
2 x CAN-FD
6 x GPIO (-24V-24V)
2 x 2-pin I2C 2.0mm Header
Capacitity Touch RST and INT Header
Dimension: 146mm x 31mm
